Montigo DelRay Linear 60" Direct Vent Gas Fireplace

The Montigo DelRay Linear 60" Basic (DRL6013NI) is built around a 60.5" wide viewing area housed in a unit just 12 3/4" deep — enough fire to anchor a room, not enough depth to swallow your wall. The linear concealed burner keeps the aesthetic clean, and the included ice fireglass media (9 lbs) gives the flame bed a modern, finished look straight out of the box.

On natural gas, output reaches 28,000 BTU/hr at 67% efficiency. Propane users can convert via the GCA047 kit (sold separately) for 25,000 BTU/hr at 64% efficiency — the flexibility to work with your fuel source without purchasing a separate unit. Gas supply pressure ranges from 5.5" to 14" W.C. on natural gas and 11" to 14" W.C. on propane, within typical residential supply parameters.

The 4"/7" direct vent system supports a maximum total vent run of 34 feet, with up to 20 feet of horizontal travel and up to 34 feet vertical — giving your installer real flexibility in placement, especially in larger or multi-story builds. Electrical requirements are standard at 115V/60Hz drawing under 12 amps, and the unit is rated for altitudes up to 4,500 feet.

Ignition is handled by Montigo's Proflame 2 Basic IPI system, which lights on demand and sheds standby energy draw when the fire isn't running. The "Basic" designation in the model name refers to the included feature set, not the quality of construction — and it's worth noting that this platform is designed for expansion. Optional accessories include the RX40 and RX60 remote controls, the DRFK1 fan kit for active heat distribution, a Reflective Glass Panel Kit, log sets, and various trim kits to tailor the surround to your install.

For installations where heat management near combustible materials is a concern, the DRL6013NI is compatible with both the Montigo Cool Wall Release and Cool Wall Advantage systems (each sold separately via the Cool Wall Release kit). The unit also carries mobile home approval — a certification that speaks directly to the engineering rigor behind its venting and clearance specifications.

Framing dimensions are 68 15/16" wide by 33 11/16" high by 14 1/4" deep, and cement board is included to support proper installation. If the standard feature set of the Basic model leaves you wanting more out of the box, the DRL6013NI-2 Full Load version is available as a separate model with additional features included standard.

• 60.5" wide viewing area with linear concealed burner and included ice fireglass media (9 lbs)
• 28,000 BTU/hr on natural gas (67% efficiency); propane-convertible via GCA047 kit for 25,000 BTU/hr
• Slim 12 3/4" unit depth with a framing depth of 14 1/4"
• Proflame 2 Basic IPI ignition — on-demand lighting, no standing pilot
• 4"/7" direct vent with up to 34 ft total vent run and 20 ft maximum horizontal
• Rated for altitudes 0–4,500 ft; approved for mobile home installation
• Cool Wall compatible — works with Montigo Cool Wall Release and Cool Wall Advantage systems
• Expandable with optional RX40/RX60 remote controls, DRFK1 fan kit, log sets, and trim kits
• Cement board included; 115V/60Hz electrical, under 12A draw
• Black finish; unit dimensions 69 1/4" W × 26 3/4" H × 12 3/4" D
